AES67 OEM Module Solutions

High-performance network audio modules to accelerate your product launch

Our YW series modules are designed for professional audio manufacturers, providing reliable AES67, ST 2110-30 and RAVENNA network audio connectivity. Whether for simple two-channel endpoints or complex mixing consoles, we have the right solution.

YW04d

Compact 4 x 4 AES67+DSP Module, suitable for portable devices

YWR04

Economic 4 x 4 Network Audio Module,Best Value Choice

YW08d/YW16/YW32

8 x 8 / 16 x 16 AES67+DSP Module, rich DSP functions

YWR08/YWR16/YWR32

High-performance Multi-channel AES67 Module, supports 48-192kHz

YWRG64/YWRG128

128-Channel AES67 Network Audio Mini-PCI Module for High-Density Digital Audio Transport

AES67 Module Comparison

Model	Channels (In/Out)	Sample Rate	Interface	DSP	Size
YW04d	4 x 4	48 / 96 / 192 kHz	I2S	✅	29 x 29 mm
YWR04	4 x 4	48 / 96 / 192 kHz	I2S	✅	29 x 29 mm
YW08d/YW16/YW32	8 x 8 / 16 x 16	48 / 96 / 192 kHz	I2S/TDM	✅	45 x 55 mm
YWR08/YWR16/YWR32	8 x 8 / 16 x 16 / 32 x 32	48 / 96 / 192 kHz	I2S/TDM	❌	45 x 55 mm
YWRG64/YWRG128	32 x 32 / 64 x 64 / 128 x 128	48 / 96 / 192 kHz	I2S/TDM	❌	45 x 55 mm

DSP Feature Comparison

Feature	D Series (DSP)	YWR04 (DSP Firmware)	V Series (RISC-V)
Signal Generator	✅	✅	❌
Noise Gate	✅	✅	❌
Feedback Suppression	✅	✅	❌
Delay	✅	✅	❌
Parametric EQ (PEQ)	✅	✅	❌
High-pass Filter	✅	✅	❌
Low-pass Filter	✅	✅	❌
Expander	✅	✅	❌
Compressor	✅	✅	❌
Limiter	✅	✅	❌
FIR Filter	✅	✅	❌
Ducking	✅	✅	❌
Mute	✅	✅	✅
Gain	✅	✅	✅
Phase Invert	✅	✅	❌
Auto Mixer	✅	❌	✅
Mix Matrix	✅	✅	✅
Gain Sharing	✅	✅	❌
Gain Control	✅	✅	❌
Gain Grouping	✅	✅	❌
Mute Grouping	✅	✅	❌
Preset Management	✅	✅	❌
Level Meter (I?S)	✅	✅	✅
